Flowserve Durco Mark 3 ISO

Fully compliant with ISO 2858 dimensional and ISO 5199 design criteria, the Durco Mark 3 ISO pump incorporates the advanced technologies of the industry-leading Durco Mark 3 ASME B73.1 pump. These include the efficiency, repeatable performance and mechanical reliability of the signature Durco Mark 3 reverse vane impeller along with its external micrometer-style impeller adjustment, SealSentry™ seal chambers, robust shaft (with low L3/D4 ratio) and bearing system design. In addition, the Mark 3 ISO pump has a two-piece power end, enabling it to be retrofitted to ISO 2858 compliant pumps, thereby offering opportunities to standardize equipment and reduce the costs of inventory

Key specifications

  • Flows up to 1400 m³/h
  • Pressure up to 25 bar

Key product features

  • Flows to 1400 m3/h
  • Heads to 220 m
  • Pressures to 25 bar
  • Temperatures from -80°C to 400°C
  • High efficiency design with low power consumption
  • Modular system resulting in maximum flexibility to adapt to a wide variety of applications
  • Heavy-duty casing, radial and trust bearings
  • SealSentry™ seal chamber extends seal life and provides advanced self-flushing capability
  • Standards ISO 2858, ISO 5199, ATEX (2014/34/EU)

Product Description

The Durco Mark 3 ISO pump line is available in four frames with 45 sizes to accommodate virtually all process flow requirements. Configurations include open or reverse vane impeller designs, recessed impeller and unitized self-priming models and close coupled arrangements. An extensive range of materials is available to address the issues of corrosion and erosion commonly found in chemical processing.

All Mark 3 ISO pumps are equipped with the IPS Beacon™ power end condition monitor. Mounted on top of the bearing housing, this is an electronic device that continuously monitors the vibration and temperature levels of the bearings, providing a visual indication when set operating limits are exceeded.


Let us help you find the right product from this series

Performance

Max. Capacity
1400 m³/h
Max. Differential Pressure
25 bar
Max. Temperature
400 Celsius
Min. Temperature
-80 Celsius
Max. Head
220 m

Certificates

ATEX

CE Marking

ISO 5199 & ISO 2858

SIA Pumptechnique
