Grundfos SMART Digital S

Grundfos SMART Digital S is a compact digital diaphragm dosing pump series for water treatment, drinking water, wastewater and industrial chemical dosing. DDA, DDC and DDE models combine speed-controlled step-motor dosing with different control levels. AxFlow can help select capacity, materials, controls and accessories. Request a quote for Grundfos SMART Digital S from AxFlow.
+
Grundfos SMART Digital S_gallery_1
Grundfos SMART Digital S_gallery_2
Grundfos SMART Digital S_gallery_1
Grundfos SMART Digital S_gallery_2
Youtube

Let us help you find the right product from this series

Key specifications

  • Flows up to 30 l/h
  • Pressure up to 16 bar

Key product features

  • Digital diaphragm dosing → Provides controlled metering for water-treatment and industrial chemical-feed duties.
  • Speed-controlled step motor → Adjusts dosing output electronically across a broad range.
  • DDA, DDC and DDE models → Allows the control level to be matched to application requirements.
  • Setting range up to 1:3000 → Supports a wide adjustable dosing range on applicable models.
  • Published capacity up to 30 l/h → Covers compact dosing duties within the verified series range.
  • Published pressure up to 16 bar → Supports higher-pressure dosing points when the correct model is selected.
  • Dosing accuracy stated at ±1% by AxFlow → Supports repeatable chemical-feed control with proper installation and calibration.
  • PP, PVC, PVDF or AISI 316 pump heads → Provides verified material options for chemical compatibility.
  • Repositionable control cube on DDA and DDC → Improves access and orientation during installation.
  • Supplied mounting plate → Simplifies positioning, service removal and pump replacement.

Product Description

SMART Digital S is designed for small and medium chemical-dosing duties where accurate capacity adjustment and a compact installation are required. AxFlow lists applications in water treatment, drinking water, wastewater and chemical processing. The range lets engineers choose between DDA, DDC and DDE control levels while keeping a common digital dosing platform, which can simplify standardization across multiple dosing points.

The series uses speed-controlled step motors and digital diaphragm dosing. DDA and DDC include a repositionable control cube, and the supplied mounting plate allows different installation positions without additional mounting accessories. AxFlow states a setting range up to 1:3000 and a wide power-supply range of 100-240 VAC at 50/60 Hz. Advanced functions such as FlowControl and AutoFlowAdapt are available on selected DDA configurations.

AxFlow publishes SMART Digital S performance up to 30 l/h and 16 bar and states dosing accuracy of ±1%. The series includes DDE, DDC and DDA models, with pump heads in PP, PVC, PVDF or AISI 316 stainless steel and O-rings in EPDM or FKM. Exact pressure, flow and function limits depend on the selected model and size.

A common digital platform across DDE, DDC and DDA can reduce the number of different operating concepts in a plant while still allowing different control needs. The mounting plate and repositionable control cube support installation and replacement work, and matched service kits simplify planned maintenance. Correct chemical-material selection and calibration help reduce dosing errors, process variation and avoidable service interventions.

Performance

Max. Capacity
30 l/h
Max. Differential Pressure
16 bar

Where to use

Chemical

Water Treatment

Drinking Water

Wastewater

The Grundfos SMART Digital S range is used for chemical dosing in water treatment, drinking water, wastewater and industrial processes. It is relevant where the verified construction and operating range match the process duty. AxFlow can help confirm whether the selected configuration fits the application.
Selection should verify required dosing rate, pressure, chemical compatibility, DDA/DDC/DDE control level, pump-head material, O-ring material, power supply and accessories. Published limits apply to specific sizes and configurations rather than every variant. The final choice should therefore be checked against the selected Grundfos product data.
Grundfos SMART Digital S is distinguished by the common speed-controlled digital dosing platform offered in DDA, DDC and DDE control levels. This defines how the product performs its intended role in the system. The practical benefit depends on matching the configuration to the actual process conditions.
Start with the required process duty and the liquid or chemical to be handled. Then confirm required dosing rate, pressure, chemical compatibility, DDA/DDC/DDE control level, pump-head material, O-ring material, power supply and accessories. AxFlow can support product selection and availability checks for the identified configuration.
AxFlow can support product identification, service planning and spare-parts selection for compatible Grundfos equipment. Exact parts and service intervals depend on the installed model, materials and operating conditions. Provide the pump or accessory identification when requesting support.
