Belzona Coating

Belzona coatings can help restore and protect pumps, impellers, casings and other fluid-handling equipment affected by erosion, corrosion, cavitation, abrasion and general wear.

AxFlow UK uses Belzona polymeric, ceramic-filled and elastomeric repair materials as part of our pump refurbishment services. Depending on the equipment, damage and site conditions, coatings can be applied at an AxFlow service centre or on site.

By rebuilding worn surfaces and protecting them against further deterioration, Belzona coating can help extend equipment life, reduce maintenance requirements and restore hydraulic performance without automatically replacing expensive pump components.

What is Belzona coating?

Belzona is a range of cold-applied polymer composites, epoxy coatings and elastomeric materials used to repair and protect industrial equipment.

For pumps and fluid-handling equipment, Belzona systems can be used to rebuild damaged metal surfaces before applying a protective coating selected for the operating environment.

Typical applications include protection against:

• Erosion and corrosion
• Cavitation damage
• Abrasive wear
• Chemical attack
• Pitting and material loss
• Continuous immersion
• General deterioration of pump wetted surfaces

The appropriate Belzona system depends on the substrate, fluid, temperature, type of damage and expected operating conditions.

What pump damage can Belzona repair?

Belzona can be considered when pump components have suffered material loss but remain suitable for repair.

Typical examples include:

Eroded pump casings
Flowing liquid and suspended solids can gradually remove material from internal surfaces.

Corroded components
Water, chemicals and aggressive process fluids can cause pitting and corrosion of casings, covers and other wetted parts.

Cavitation damage
Repeated formation and collapse of vapour bubbles can cause severe localised pitting around impellers and pump casings.

Worn impellers
Damaged hydraulic surfaces can sometimes be rebuilt and protected rather than immediately replacing the complete impeller.

Damaged wear areas and clearances
Suitable repair compounds can be used to rebuild metal surfaces before machining or finishing where required.

The suitability of any repair should be assessed by an experienced engineer before coating is specified.

What are the benefits of Belzona pump coatings?

A correctly selected and applied coating can provide several benefits.

Extend pump component life

Protective coatings isolate the underlying metal from aggressive operating conditions, helping reduce further erosion or corrosion.

Restore damaged surfaces

Polymeric repair compounds can rebuild areas affected by pitting, erosion or material loss before the protective coating is applied.

Help restore pump performance

Damage and rough internal surfaces can increase hydraulic losses. Restoring the original profile and applying a smooth protective finish can help recover lost pump performance.

Reduce replacement costs

Repairing an otherwise serviceable casing or component may avoid the cost and lead time associated with sourcing a new or obsolete replacement part.

Reduce future maintenance

Protecting vulnerable surfaces against recurring erosion or corrosion can increase the interval between major refurbishment work.
