Argal - BASIS
Category: Pumps
SubCategory: CentrifugalPumps
Manufacturer: Argal
Industry: Agriculture;Chemical;HeatingWaterSanitation;WaterTreatment
SubCategory: CentrifugalPumps
Manufacturer: Argal
Industry: Agriculture;Chemical;HeatingWaterSanitation;WaterTreatment
Mag drive pumps for flows up to 3.5 m3/hr, heads to 8 m.
+
Let us help you find the right product from this product line
Key specifications
- Flows up to 70 l/min
FEATURES AND BENEFITS
- Identical dimensions to Iwaki pumps.
- BSP, NPT and hose connections.
- 50/60 hz IEC or UL motors
- All models have encapuslated impeller magnets.
BASIS pumps are single stage, and magnetic driven centrifugalpumps. The range includes 5 models with capacities between 15 and 70 l/min.
The volute casing is realised with Polypropylene reinforcedwith fiberglass, by a monolithic injection in themould and with an encapsulated front shaft bearing.The connections can be hosed or screwed.
• The rear casing is obtained through the same processand hosts the rear shaft bearing.
• The coupled volute and rear casing are realised to beleakage proof.
• The impeller is made of Polypropylene reinforced with GFR.COMPONENTSTMB Mode
Construction
Materials
ECTFE, Polypropylene
Coupled
Close
Performance
Max. capacity
70 l/min
Max. temperature
80 Celsius
Min. capacity
15 l/min
Min. temperature
-30 Celsius
Max. head
11 m
Certificates
ATEX
FDA pumps, valves, mixers, homogenizers, heat exchangers and spare parts
UL
