Wernert FK Series
Category: Pumps
SubCategory: CentrifugalPumps
Manufacturer: WernertPumpen
Industry:
SubCategory: CentrifugalPumps
Manufacturer: WernertPumpen
Industry:
ISO 2858 lined slurry pumps for corrosive and abrasive solid ladened liquids 200 m3/hr heads of 40 m
+
Let us help you find the right product from this product line
Key specifications
- Flows up to 200 m³/h
- Pressure Up To 4 bar
User benefits
- Completely cast iron clad, all forces from piping are fully supported by metal casing.
- Up to 40% solids content.
- Particle size up to 25 mm.
- Temperatures to 165°C.
- Close coupled to offer compact dimensions.
FEATURES AND BENEFITS
- Impeller of Chlorine-resistant PE, PVDF, WERNIT, PTFE.
- Cooling rings positioned around bearing housing.
- High Load, fixed/Movable bearings.
- Support foot fixing, located at the bearing housing
- Single stage process designed radial centrifugal pump.
- May be used in areas with explosive atmosphere – directive 94/9/EG
- Semi-open or closed impeller.
- WERNERT single bellows type mechanical seal or Double acting mechanical seal of most well known seal manufacturers.
- Thick-walled interchangeable plastic parts.
- ATEX rated.
Description
Close coupled ISO 2858 lined slurry pumps designed to convey aggressive, solid ladened and toxic liquids. They are designed around a solid pump casing which results in a particularly robust construction.
