Realax IP Series
Hose pumps up to 25 m3/hr
Product description
A suite of industrial hose pumps that utilise shoes to compress the hose rather than rollers giving a more even and longer sealing area. They are fitted with inverter driven motors and have sturdy reinforced hoses.
Product features
- Suction lift to 9 metres.
- Reversible rotation.
- Can be accompanied with pulsation dampeners.
- Hose leakage detector available.
- FDA materials available.
- Available with casing coated in Halar (PTFE).`
Specifications
| Type | Peristaltic Pumps |
| Alignment | Horizontal |
| Seal | Seal-Less |
| Coupled | Close |
| Manufacturer |
|
| Max. capacity | 35 m³/h |
| Min. viscosity | 1 mPa·s |
| Max. viscosity | 25000 mPa·s |
| Max. temperature | 65° Celsius |
| Max. differential head/pressure | 8 bar |
| Model | Max. capacity [m3/h] | Max. diff. press. [bar] | Disp. rev. [l/rev.] | Max. temp. [C] | |
|---|---|---|---|---|---|
| IP-30 | 1.7 | 8 | 0.433 | 65 | 62 |
| IP-40 | 3.4 | 8 | 0.86 | 65 | 89 |
| IP-50 | 5 | 8 | 1.47 | 65 | 140 |
| IP-60 | 10 | 8 | 3.16 | 65 | 235 |
| IP-70 | 18.5 | 8 | 6.72 | 65 | 440 |
| IP-70D | 35 | 8 | 13.4 | - | 850 |
All certifications and standards listed for each product are certified by the manufacturer of each product and remain the manufacturer’s liability.
